AX−SFEU, AX−SFEU−API

www.onsemi.com

Table 11. REGISTERS

Number

Name

Description

Default

Range

Units

300

Out Of Band Period

AX−SFEU sends periodic static

messages to indicate that they are

alive. Set to 0 to disable.

0−24

hours

302

Power Level

The output power of the radio.

Note: This setting is used for all TX

modes except AT$CW.

0−14

dBm

410

Encryption Key

Configuration

Set to zero for normal operation. Set

to one for use with the SIGFOX

Network Emulator Kit (SNEK)

0−1

0: private key

1: public key

411

(Note 4)

Enable Test Credentials

for Sigfox Certification

Set to zero for use of regular device

ID and key.

Setting to one switches to test

credentials for Sigfox Certification

(Sigfox ID = 0xFEDCBA98.

Key=0x0123456789ABCDEF012345

6789ABCDEF)

0−1

0: regular ID and key

1: test credentials for

Sigfox certification

500

(Note 4)

RSSI Offset

RSSI offset value can be applied to

fune tune the RSSI level that the

deice reports

−128…127

4. This register is only available only in AX−SFEU−1−03 and later.
