CRO2170B 데이터시트(PDF) 2 Page - Z-Communications, Inc

부품명 CRO2170B
상세설명  VOLTAGE CONTROLLED OSCILLATOR
PDF  2 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  ZCOMM [Z-Communications, Inc]
홈페이지  http://www.zcomm.com
Logo ZCOMM - Z-Communications, Inc

CRO2170B 데이터시트(HTML) 2 Page - Z-Communications, Inc

  CRO2170B Datasheet HTML 1Page - Z-Communications, Inc CRO2170B Datasheet HTML 2Page - Z-Communications, Inc
Zoom Inzoom in Zoom Outzoom out
 2 / 2 page
background image
1950
2000
2050
2100
2150
2200
2250
2300
2350
00.5
11.5
2
2.5
33.5
4
4.5
-1
0
1
2
3
4
5
6
7
8
9
10
2010
2040
2069
2099
2130
2164
2199
2233
2264
2289
LOW COST - HIGH PERFORMANCE
VOLTAGE CONTROLLED OSCILLATOR
© Z-Communications, Inc.
Page 2
Printed in the U.S.A.
CRO2170B
TUNING CURVE, typ.
POWER CURVE, typ.
PAGE 2
PHYSICAL DIMENSIONS
°c
°c
°c
85
-40
25
°c
25
0.475
0.000
0.025
0.500
0.405
0.305
0.205
0.105
0.115
0.215
0.315
0.415
GROUND PLANE SOLDER PLATED
BOTTOM VIEW
P1
P3
P2
.037
SEE NOTE 3
TYPICAL OF ALL PADS
.026
.031
.052
.114
.070
TABS RANGE:
SEE NOTE 5.
(4 PLACES)
DETAIL A
P1=VT
P2=RF OUT
P3=Vcc
.220
.034
0.000
.070 TYP
.150
TYP
MINI-16
415-0061 REV. D
(DRAWING NOT TO SCALE)
SEE DETAIL 'A'
NOTES:
THE INSIDE RADIUS OF ALL 16 HALF HOLES
AT THE PERIMETER OF THE BOARD ARE
PLATED TO PROVIDE A SURFACE FOR THE
ATTACHMENT OF THE VCO TO A PCB,
IN 13 LOCATIONS, WITH 3 PADS BEING
USED FOR ELECTROMECHANICAL INTERFACE.
2. THE SURFACE OF THE SHIELD IS TIN PLATED
AND MAY BE SOLDERED TO. THE SHIELD'S
3. THE GROUND PLANE IS GROUND AND ATTACHES
TO A GROUND TRACK ON THE UPPER SIDE OF
THE BOARD AS WELL AS THE SHIELD BY PTH.
1.
16 SOLDER LOCATIONS REQUIRED.
BASE METAL IS COLD ROLLED STEEL.
.XXX= ± .010
TOLERANCES
4. UNLESS OTHERWISE NOTED ALL DIMENSIONS
ARE IN INCHES.
5. UNLESS OTHERWISE NOTED ALL TOLERANCES
ARE AS FOLLOWS:
TUNING VOLTAGE (Vdc)
FREQUENCY (MHz)
