AM6442...ALV datasheet(98/244 Pages) TI

98 / 244 page

7 Specifications

Note

All specifications listed are preliminary and may change during device characterization.

7.1 Absolute Maximum Ratings

over operating junction temperature range (unless otherwise noted)

(1)(2)

PARAMETER

MIN

MAX UNIT

VDD_CORE

Core supply

-0.3

1.05

VDDR_CORE

RAM supply

-0.3

1.05

VDD_MMC0

MMC0 PHY core supply

-0.3

1.05

VDD_DLL_MMC0

MMC0 PLL analog supply

-0.3

1.05

VDDA_0P85_SERDES0

SERDES0 0.85 V analog supply

-0.3

1.05

VDDA_0P85_SERDES0_C

SERDES0 clock 0.85 V analog supply

-0.3

1.05

VDDA_0P85_USB0

USB0 0.85 V analog supply

-0.3

1.05

VDDS_DDR

DDR PHY IO supply

-0.3

TBD

VDDS_DDR_C

DDR clock IO supply

-0.3

TBD

VDDS_MMC0

MMC0 PHY IO supply

-0.3

2.2

VDDS_OSC

MCU_OSC0 supply

-0.3

2.2

VDDA_MCU

POR and MCU PLL analog supply

-0.3

2.2

VDDA_ADC0

ADC0 analog supply

-0.3

2.2

VDDA_PLL0

Main, PER1, and R5F PLL analog supply

-0.3

2.2

VDDA_PLL1

ARM and DDR PLL analog supply

-0.3

2.2

VDDA_PLL2

PER0 PLL analog supply

-0.3

2.2

VDDA_1P8_SERDES0

SERDES0 1.8 V analog supply

-0.3

2.2

VDDA_1P8_USB0

USB0 1.8 V analog supply

-0.3

2.2

VDDA_TEMP0

TEMP0 analog supply

-0.3

2.2

VDDA_TEMP1

TEMP1 analog supply

-0.3

2.2

VPP

eFuse ROM programming supply

-0.3

TBD

VDDSHV_MCU

IO supply for IO MCU

-0.3

3.8

VDDSHV0

IO supply for IO group 0

-0.3

3.8

VDDSHV1

IO supply for IO group 1

-0.3

3.8

VDDSHV2

IO supply for IO group 2

-0.3

3.8

VDDSHV3

IO supply for IO group 3

-0.3

3.8

VDDSHV4

IO supply for IO group 4

-0.3

3.8

VDDSHV5

IO supply for IO group 5

-0.3

3.8

VDDA_3P3_USB0

USB0 3.3 V analog supply

-0.3

3.8

VDDA_3P3_SDIO

SDIO 3.3 V analog supply

-0.3

TBD

Steady-state max voltage at all fail-safe IO pins

MCU_PORz

-0.3

2.2

MCU_I2C0_SCL, MCU_I2C0_SDA,

I2C0_SCL, I2C0_SDA, EXTINTn

-0.3

TBD

VMON_1P8_MCU, VMON_1P8_SOC

-0.3

2.2

VMON_3P3_MCU, VMON_3P3_SOC

-0.3

3.8

VMON_VSYS(3)

-0.3

2.2

AM6442, AM6441, AM6421, AM6412, AM6411

SPRSP56D – JANUARY 2021 – REVISED JULY 2022

www.ti.com

Submit Document Feedback

Product Folder Links: AM6442 AM6441 AM6421 AM6412 AM6411
