Table 6-59. PRU_ICSSG0 Signal Descriptions (continued)
SIGNAL NAME [1]
PIN TYPE [2]
DESCRIPTION [3]
ALV PIN [4]
PRG0_PRU0_GPO10
IO
PRU-ICSSG PRU Data Output
AA5
PRG0_PRU0_GPO11
IO
PRU-ICSSG PRU Data Output
Y3
PRG0_PRU0_GPO12
IO
PRU-ICSSG PRU Data Output
AA3
PRG0_PRU0_GPO13
IO
PRU-ICSSG PRU Data Output
R6
PRG0_PRU0_GPO14
IO
PRU-ICSSG PRU Data Output
V4
PRG0_PRU0_GPO15
IO
PRU-ICSSG PRU Data Output
T5
PRG0_PRU0_GPO16
IO
PRU-ICSSG PRU Data Output
U4
PRG0_PRU0_GPO17
IO
PRU-ICSSG PRU Data Output
U1
PRG0_PRU0_GPO18
IO
PRU-ICSSG PRU Data Output
V1
PRG0_PRU0_GPO19
IO
PRU-ICSSG PRU Data Output
W1
PRG0_PRU1_GPI0
I
PRU-ICSSG PRU Data Input
Y2
PRG0_PRU1_GPI1
I
PRU-ICSSG PRU Data Input
W2
PRG0_PRU1_GPI2
I
PRU-ICSSG PRU Data Input
V3
PRG0_PRU1_GPI3
I
PRU-ICSSG PRU Data Input
T4
PRG0_PRU1_GPI4
I
PRU-ICSSG PRU Data Input
W3
PRG0_PRU1_GPI5
I
PRU-ICSSG PRU Data Input
P4
PRG0_PRU1_GPI6
I
PRU-ICSSG PRU Data Input
R5
PRG0_PRU1_GPI7
I
PRU-ICSSG PRU Data Input
W5
PRG0_PRU1_GPI8
I
PRU-ICSSG PRU Data Input
R1
PRG0_PRU1_GPI9
I
PRU-ICSSG PRU Data Input
Y5
PRG0_PRU1_GPI10
I
PRU-ICSSG PRU Data Input
V6
PRG0_PRU1_GPI11
I
PRU-ICSSG PRU Data Input
W4
PRG0_PRU1_GPI12
I
PRU-ICSSG PRU Data Input
Y4
PRG0_PRU1_GPI13
I
PRU-ICSSG PRU Data Input
T6
PRG0_PRU1_GPI14
I
PRU-ICSSG PRU Data Input
U6
PRG0_PRU1_GPI15
I
PRU-ICSSG PRU Data Input
U5
PRG0_PRU1_GPI16
I
PRU-ICSSG PRU Data Input
AA4
PRG0_PRU1_GPI17
I
PRU-ICSSG PRU Data Input
V5
PRG0_PRU1_GPI18
I
PRU-ICSSG PRU Data Input
P5
PRG0_PRU1_GPI19
I
PRU-ICSSG PRU Data Input
R2
PRG0_PRU1_GPO0
IO
PRU-ICSSG PRU Data Output
Y2
PRG0_PRU1_GPO1
IO
PRU-ICSSG PRU Data Output
W2
PRG0_PRU1_GPO2
IO
PRU-ICSSG PRU Data Output
V3
PRG0_PRU1_GPO3
IO
PRU-ICSSG PRU Data Output
T4
PRG0_PRU1_GPO4
IO
PRU-ICSSG PRU Data Output
W3
PRG0_PRU1_GPO5
IO
PRU-ICSSG PRU Data Output
P4
PRG0_PRU1_GPO6
IO
PRU-ICSSG PRU Data Output
R5
PRG0_PRU1_GPO7
IO
PRU-ICSSG PRU Data Output
W5
PRG0_PRU1_GPO8
IO
PRU-ICSSG PRU Data Output
R1
PRG0_PRU1_GPO9
IO
PRU-ICSSG PRU Data Output
Y5
PRG0_PRU1_GPO10
IO
PRU-ICSSG PRU Data Output
V6
PRG0_PRU1_GPO11
IO
PRU-ICSSG PRU Data Output
W4
PRG0_PRU1_GPO12
IO
PRU-ICSSG PRU Data Output
Y4
PRG0_PRU1_GPO13
IO
PRU-ICSSG PRU Data Output
T6
PRG0_PRU1_GPO14
IO
PRU-ICSSG PRU Data Output
U6
AM6442, AM6441, AM6421, AM6412, AM6411
SPRSP56D – JANUARY 2021 – REVISED JULY 2022
www.ti.com
82
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
Product Folder Links: AM6442 AM6441 AM6421 AM6412 AM6411
