over recommended operating conditions (unless otherwise noted)

PARAMETER

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Input Leakage Current

ADC0_AIN[7:0] =

VDDA_ADC0

ADC0_AIN[7:0] = VSS

μA

(1)

ADC0 can be configured to operate in General Purpose Input mode, where all ADC0_AIN[7:0] inputs are globally enabled to operate

as digital inputs via the ADC0_CTRL register (gpi_mode_en = 1).

7.7.8 USB2PHY Electrical Characteristics

Note

USB0 interface is compliant with Universal Serial Bus Revision 2.0 Specification dated April 27, 2000

including ECNs and Errata as applicable.

7.7.9 SERDES Electrical Characteristics

Note

The PCIe interface is compliant with the electrical parameters specified in PCI Express® Base

Specification Revision 4.0, February 19, 2014.

Note

USB0 instance is compliant with the USB3.1 SuperSpeed Transmitter and Receiver Normative

Electrical Parameters as defined in the Universal Serial Bus 3.1 Specification, Revision 1.0 , July

26, 2013.

7.7.10 DDR Electrical Characteristics

Note

The DDR interface is compatible with DDR4 and LPDDR4 devices

AM6442, AM6441, AM6421, AM6412, AM6411

SPRSP56D – JANUARY 2021 – REVISED JULY 2022

www.ti.com

108

Submit Document Feedback

Product Folder Links: AM6442 AM6441 AM6421 AM6412 AM6411
