Table 6-60. PRU_ICSSG1 Signal Descriptions (continued)
SIGNAL NAME [1]
PIN TYPE [2]
DESCRIPTION [3]
ALV PIN [4]
PRG1_IEP1_EDC_SYNC_OUT0
O
PRU_ICSSG Industrial Ethernet Distributed Clock
Sync Output
V12
PRG1_IEP1_EDC_SYNC_OUT1
O
PRU_ICSSG Industrial Ethernet Distributed Clock
Sync Output
AA14
PRG1_MDIO0_MDC
O
PRU-ICSSG MDIO Clock
Y6
PRG1_MDIO0_MDIO
IO
PRU-ICSSG MDIO Data
AA6
PRG1_PRU0_GPI0
I
PRU-ICSSG PRU Data Input
Y7
PRG1_PRU0_GPI1
I
PRU-ICSSG PRU Data Input
U8
PRG1_PRU0_GPI2
I
PRU-ICSSG PRU Data Input
W8
PRG1_PRU0_GPI3
I
PRU-ICSSG PRU Data Input
V8
PRG1_PRU0_GPI4
I
PRU-ICSSG PRU Data Input
Y8
PRG1_PRU0_GPI5
I
PRU-ICSSG PRU Data Input
V13
PRG1_PRU0_GPI6
I
PRU-ICSSG PRU Data Input
AA7
PRG1_PRU0_GPI7
I
PRU-ICSSG PRU Data Input
U13
PRG1_PRU0_GPI8
I
PRU-ICSSG PRU Data Input
W13
PRG1_PRU0_GPI9
I
PRU-ICSSG PRU Data Input
U15
PRG1_PRU0_GPI10
I
PRU-ICSSG PRU Data Input
U14
PRG1_PRU0_GPI11
I
PRU-ICSSG PRU Data Input
AA8
PRG1_PRU0_GPI12
I
PRU-ICSSG PRU Data Input
U9
PRG1_PRU0_GPI13
I
PRU-ICSSG PRU Data Input
W9
PRG1_PRU0_GPI14
I
PRU-ICSSG PRU Data Input
AA9
PRG1_PRU0_GPI15
I
PRU-ICSSG PRU Data Input
Y9
PRG1_PRU0_GPI16
I
PRU-ICSSG PRU Data Input
V9
PRG1_PRU0_GPI17
I
PRU-ICSSG PRU Data Input
U7
PRG1_PRU0_GPI18
I
PRU-ICSSG PRU Data Input
V7
PRG1_PRU0_GPI19
I
PRU-ICSSG PRU Data Input
W7
PRG1_PRU0_GPO0
IO
PRU-ICSSG PRU Data Output
Y7
PRG1_PRU0_GPO1
IO
PRU-ICSSG PRU Data Output
U8
PRG1_PRU0_GPO2
IO
PRU-ICSSG PRU Data Output
W8
PRG1_PRU0_GPO3
IO
PRU-ICSSG PRU Data Output
V8
PRG1_PRU0_GPO4
IO
PRU-ICSSG PRU Data Output
Y8
PRG1_PRU0_GPO5
IO
PRU-ICSSG PRU Data Output
V13
PRG1_PRU0_GPO6
IO
PRU-ICSSG PRU Data Output
AA7
PRG1_PRU0_GPO7
IO
PRU-ICSSG PRU Data Output
U13
PRG1_PRU0_GPO8
IO
PRU-ICSSG PRU Data Output
W13
PRG1_PRU0_GPO9
IO
PRU-ICSSG PRU Data Output
U15
PRG1_PRU0_GPO10
IO
PRU-ICSSG PRU Data Output
U14
PRG1_PRU0_GPO11
IO
PRU-ICSSG PRU Data Output
AA8
PRG1_PRU0_GPO12
IO
PRU-ICSSG PRU Data Output
U9
PRG1_PRU0_GPO13
IO
PRU-ICSSG PRU Data Output
W9
PRG1_PRU0_GPO14
IO
PRU-ICSSG PRU Data Output
AA9
PRG1_PRU0_GPO15
IO
PRU-ICSSG PRU Data Output
Y9
PRG1_PRU0_GPO16
IO
PRU-ICSSG PRU Data Output
V9
PRG1_PRU0_GPO17
IO
PRU-ICSSG PRU Data Output
U7
PRG1_PRU0_GPO18
IO
PRU-ICSSG PRU Data Output
V7
PRG1_PRU0_GPO19
IO
PRU-ICSSG PRU Data Output
W7
www.ti.com
AM6442, AM6441, AM6421, AM6412, AM6411
SPRSP56D – JANUARY 2021 – REVISED JULY 2022
Copyright © 2022 Texas Instruments Incorporated
Submit Document Feedback
85
Product Folder Links: AM6442 AM6441 AM6421 AM6412 AM6411
