AP43771

Document number: DS41431 Rev. 6 - 3

4 of 10

www.diodes.com

June 2022

© 2022 Copyright Diodes Incorporated. All Rights Reserved.

AP43771

Absolute Maximum Ratings (Note 4)

Symbol

Parameter

Rating

Unit

VCC

Input Voltage at VCC Pin

-0.3 to 24

V

VFB, VIFB, VOTP

Input Voltage at VFB, IFB, OTP Pins

-0.3 to 7

V

VBUS, VPWR_EN, VISENP,VOCDRV

Input Voltage at VBUS, PWR_EN, ISENP, OCDRV

Pins

-0.3 to 24

V

—

Voltage from PWR_EN to VCC Pin

-16 to 7

V

VV5V

Input Voltage at V5V Pin

-0.3 to 7

V

VCC1, VCC2

Input Voltage at CC1, CC2 Pins

-0.3 to 7

V

VDP, VDN

Input Voltage at DP, DN Pins

-0.3 to 7

V

TJ

Operating Junction Temperature

-40 to +150

°C

TSTG

Storage Temperature

-65 to +150

°C

TLEAD

Lead Temperature (Soldering, 10s)

+300

°C

θJA

Thermal Resistance (Junction to Ambient)

(Note 5)

122

°C/W

θJC

Thermal Resistance (Junction to Case) (Note 5)

27

°C/W

—

ESD (Human Body Model) Voltage on DP, DN Pins

8

kV

—

ESD (Human Body Model) Voltage on VBUS,

ISENP, PWR_EN, VCC, OCDRV, OTP, V5V, IFB,

VFB, CC1, CC2 Pins

2

kV

—

ESD (Charged Device Model)

750

V

Notes:

4. Stresses greater than those listed under Absolute Maximum Ratings can cause permanent damage to the device. These are stress ratings only, and

functional operation of the device at these or any other conditions beyond those indicated under Recommended Operating Conditions is not implied.

Exposure to Absolute Maximum Ratings for extended periods can affect device reliability.

5. Test condition: Device mounted on FR-4 substrate PC board, 2oz copper, with the minimum footprint.

Recommended Operating Conditions

Symbol

Parameter

Min

Max

Unit

VCC

Power Supply Voltage

3.3

16

V

TOP

Operating Temperature Range

-40

+85

°C
