Page 8

ams Datasheet

Document Feedback

[v1-06] 2018-Jun-20

AS5600 − Magnetic Characteristics

Figure 11:

Magnetic Characteristics

Figure 12:

System Specifications

Symbol

Parameter

Conditions

Min

Max

Units

Orthogonal magnetic field

strength, regular output noise

ON_SLOW and ON_FAST

Required orthogonal component

of the magnetic field strength

measured at the die's surface

along a circle of 1mm

Bz_ERROR

Minimum required orthogonal

magnetic field strength,

Magnet detection level

8mT

Symbol

Parameter

Conditions

Min

Typ

Max

Units

RES

Resolution

bit

INL_BL

System INL

Deviation from best line fit; 360°

maximum angle, no magnet

displacement, no

zero-programming performed

(PWM, I²C)

±1

degree

ON_SLOW

RMS output

noise (1 sigma)

Orthogonal component for the

magnetic field within the specified

range (Bz), after 2.2 ms;

SF = 00

0.015

degree

ON_FAST

RMS output

noise (1 sigma)

Orthogonal component for the

magnetic field within the specified

range (Bz), after 286 μs, SF=11

0.043

degree

Magnetic Characteristics

System Characteristics
