background image
11
Link Terminals with 32 Inputs
B7AS
Incorporates 2 Sets of 16 Input Points in
a Single Unit
Select either normal I/O delay time or short I/O
delay time using a switch.
Compact dimensions contribute to space savings.
Use for either contact or no-contact inputs.
Ordering Information
Model Number Legend
B7AS - T 3 B S
12 3 4
1. Series
S:
Small
2. Input/Output Classification
T:
Input
3. Number of I/O Points
3:
32
4. Input Logic/Internal I/O Common
B:
NPN compatible
5. Appearance
S:
Screw terminals
5
Product List
Refer to page 114 for details.
I/O Combinations
Refer to pages 1 to 5 for details.
