Electrical ratings

Table 1. Absolute maximum ratings

Symbol

Parameter

Value

Unit

VCES

Collector-emitter voltage (VGE = 0)

650

V

IC

Continuous collector current at TC = 25 °C

40

A

Continuous collector current at TC = 100 °C

20

A

ICP(1)

Pulsed collector current

80

A

VGE

Gate-emitter voltage

±20

V

IF

Continuous forward current at TC = 25 °C

40

A

Continuous forward current at TC = 100 °C

20

A

IFP(1)

Pulsed forward current

80

A

PTOT

Total dissipation at TC = 25 °C

166

W

TSTG

Storage temperature range

-55 to 150

°C

TJ

Operating junction temperature range

-55 to 175

°C

1. Pulse width limited by maximum junction temperature.

Table 2. Thermal data

Symbol

Parameter

Value

Unit

RthJC

Thermal resistance junction-case IGBT

0.9

°C/W

RthJC

Thermal resistance junction-case diode

2.08

°C/W

RthJA

Thermal resistance junction-ambient

62.5

°C/W
