background image
ＳＰＥＣＩＦＩＣＡＴＩＯＮ
ＴＹＰＥ
ＣＤＲＨ６４
1．APPEARANCE
1-1．DIMENSIONS(ｍｍ)
＊ DIMENSIONS WITHOUT TOLERANCE ARE APPROX.
1-2．STAMP(E.
)
1-3. DIMENSION RECOMMENDED (mm)
2．COIL SPECIFICATION
2-1．CONNECTION (BOTTOM
)
PLEASE COAT WITH SILK SCREEN BETWEEN THE TWO TERMINALS.
ELECTRODE
6.2±0.3
1.5
MAX.5.0
0.1
DIRECTLY STAMP
UNFIXED POSITION
DATE CODE
100
1.9
PART OF SILK SCREEN
DIMENSION OF CDRH64
compliance
Cd:Max.0.01wt%
others:Max.0.1wt%
RoHS
1
