background image
ＳＰＥＣＩＦＩＣＡＴＩＯＮ
ＴＹＰＥ
ＣＤＲＨ６４Ｂ
1．
1-1．DIMENSIONS(mm)
＊ DIMENSIONS WITHOUT TOLERANCE ARE APPROX.
1-2．STAMP (E.
)
-3. DIMENSION RECOMMENDED (mm)
2．COIL SPECIFICATION
2-1．CONNECTION (BOTTOM
)
PLEASE COAT WITH SILK SCREEN BETWEEN THE TWO TERMINALS.
DIRECTLY STAMP
UNFIXED POSITION
DATE CODE
100
PART OF SILK SCREEN
1.9
MAX.5.0
0.6
0.1
1.5±0.2
6.2±0.3
ELECTRODE
compliance
Cd:Max.0.01wt%
others:Max.0.1wt%
RoHS
1
