ＳＰＥＣＩＦＩＣＡＴＩＯＮ
ＴＹＰＥ
ＣＤＲＨ７３
1．APPEARANCE
1-1.DIMENSION （mm）
＊ DIMENSIONS WITHOUT TOLERANCE ARE APPROX.
1-2.STAMP (E.
)
-3.DIMENSION RECOMMENDED (mm)
2．COIL SPECIFICATION
PLEASE COAT WITH SILK SCREEN BETWEEN THE TWO TERMINALS.
2-1.CONNECTION (BOTTOM
)
ELECTRODE
7.3±0.2
1.8
3.2±0.2
0.2
DIRECTLY STAMP
DATE CODE
UNFIXED THE POSITION
10 0
2.2
PART OF SILK SCREEN
DIMENSION OF CDRH73
compliance
Cd:Max.0.01wt%
others:Max.0.1wt%
RoHS
1
