 2 / 3 page
background image
MSC1075MP
Advanced Power Technology reserves the right to change, without notice, the specifications and information contained herein
Visit our website at WWW.ADVANCEDPOWER.COM or contact our factory direct.
ELECTRICAL SPECIFICATIONS (Tcase = 25
ELECTRICAL SPECIFICATIONS (Tcase = 25
°°C)
C)
STATIC
Value
Symbol
Test Conditions
Min.
Typ.
Max.
Units
BVCBO
IC = 10 mA
IE = 0 Ma
65
V
BVCES
IC = 25 mA
VBE = 0 V
65
V
BVEBO
IE = 10 mA
IC = 0 mA
3.5
V
ICES
VCE = 50 V
IE = 0 mA
5
mA
hFE
VCE = 5 V
IC = .1 A
10
DYNAMIC
Value
Symbol
Test Conditions
Min.
Typ.
Max.
Units
POUT
f = 1025 – 1150 MHz
PIN = 13.0 W
VCE = 50 V
75
W
GP
f = 1025 – 1150 MHz
PIN = 13.0 W
VCE = 50 V
7.5
dB
Note:
Pulse width = 10µSec. Duty Cycle = 1%
This device is suitable for use under other pulse width/duty cycle conditions.
Please contact the factory for specific applications assistance.
