FT93x Datasheet Embedded Microcontroller Datasheet

Version 1.5

Document Reference No.: BRT_000051

Clearance No.: BRT#049

7.4

QFN-68/56/48 Device Marking

7.4.1 FT93XQ Top Side

Figure 7-4 FT93XQ Top Side

Notes:

1. FT93XQ symbol stands for FT930Q, FT931Q, FT932Q, and FT933Q.

2. YYWW = Date Code, where YY is year and WW is week number and following character B

indicates the silicon revision B.

3. Pre date code 1727 the company logo was FTDI

4. Marking alignment should be centre justified.

5. Laser marking should be used.

All marking dimensions should be marked proportionally. Marking font should be using standard font

(Roman Simplex).

BRT

XXXXXXXXXX

FT93XQ

Line 1 – Company Logo

Line 4 – Date Code,

Revision

Line 2 – Wafer Lot Number

68/56/48

Line 3 – Part Number

YYWW-B
