FEATURES



EFFICIENCY UP TO 90%



CONSTANT CURRENT LED DRIVER



WIDE INPUT AND OUTPUT VOLTAGE RANGE



INPUT VOLTAGE UP TO 36V



PWM DIMMING CONTROL



SHORT CIRCUIT AND OVERTEMPERATURE

PROTECTED



INTERNAL SMD TECHNOLOGY



FULLY ISOLATED PLAST2C CASE WITH IP67

LEVEL



UL 94V-0 PACKAGE MATERIAL



RoHS COMPLIANT



3 YEARS WARRANTY

 DESCRIPTION

CLE-12 series is a high efficiency, constant current and Buck-Boost DC/DC

converter. The LED DRIVER operates from an input voltage 9Vdc to 36Vdc and

provides an externally adjustable output current of up to 600mA and output power up

to 16 watts. It is able to include the function of Over temperature protection(OTP),

Over Voltage protection(OVP), PWM Dimming and ON/OFF.

The device can extensively be used for General Industrial High Power LED Lighting,

Desk Lights and Room Lighting, Building and Street Lighting, Industrial Display

Backlight etc.

 SELECTION GUIDE

MODEL

NUMBER

INPUT

NOMINAL

VOLTAGE

(VDC)

INPUT

VOLTAGE

RANGE

(VDC)

OUTPUT

VOLTAGE

RANGE

(VDC)

OUTPUT

CURRENT

RANGE

(mA)

DIMMING

CONTROL

EFF

(%, Typ.)

CLE-12-0.30D(W)

12

9-36

2-40

0-300

PWM

90

CLE-12-0.35D(W)

12

9-36

2-40

0-350

PWM

90

CLE-12-0.50D(W)

12

9-30

2-32

0-500

PWM

90

CLE-12-0.60D(W)

12

9-28

2-30

0-600

PWM

90

CLE-12 SERIES

Constant Current LED Driver
