176 / 226 page  KSZ9563R DS00002419D-page 176 2017-2018 Microchip Technology Inc. 5.2.10.2 Port MSTP Pointer Register 5.2.10.3 Port MSTP State Register There are eight MSTPs, and the MSTP Pointer in the Port MSTP Pointer Register is used as an index to select a par- ticular MSTP when reading or writing this register. 5.2.11 PORT N: PORT SWITCH PTP CONTROL REGISTERS (0xNC00 - 0xNCFF) 5.2.11.1 Port PTP Receive Latency Register Address: 0xNB01 Port N: 1-3 Size: 8 bits Bits Description Type Default 7:3 RESERVED R/W 0000_0b 2:0 MSTP Pointer Points to one of the 8 MSTPs. It is used as an index when reading or writing the Port MSTP State Register. R/W 000b Address: 0xNB04 Port N: 1-3 Size: 8 bits Bits Description Type Default 7:3 RESERVED RO 0000_0b 2 Port Transmit Enable 1 = Enable packet transmission on the port 0 = Disable packet transmission on the port R/W 1b 1 Port Receive Enable 1 = Enable packet reception on the port 0 = Disable packet reception on the port R/W 1b 0 Port Learning Disable 1 = Disable switch address learning on the port 0 = Enable switch address learning on the port R/W 0b Address: 0xNC00 - 0xNC01 Port N: 1-3 Size: 16 bits Bits Description Type Default 15:0 PTP Port N RX Latency in Nanoseconds (PTP_RX_LATENCY[15:0]) This field is used to set the fixed receive delay value from the port N wire to the RX timestamp reference point. The default value is 415ns. R/W 0x019F |
|
