 2017-2018 Microchip Technology Inc.

DS00002419D-page 57

KSZ9563R

4.11

MAC Interface (RGMII/MII/RMII Port 3)

Strapping options are used to individually select any of these MAC interface options for port 3:

• Media Independent Interface (MII): Supports 100 and 10 Mbps data rates

• Reduced Media Independent Interface (RMII): Supports 100 and 10 Mbps data rates

• Reduced Gigabit Media Independent Interface (RGMII): Supports 1000, 100 and 10 Mbps data rates

Strapping options are used to set port 3 to either MII, RMII, or RGMII at the deassertion of reset. Refer to Section 3.2.1,

"Configuration Straps," on page 16 for additional information.

Note that the signals on the KSZ9563R MAC interfaces are named as they would be for a PHY: the TX direction is into

the KSZ9563R, while the RX direction is out of the KSZ9563R, as if to a host processor with integrated MAC. Signal

connection to such a “MAC” device is TX-to-TX, and RX-to-RX.

An external PHY (such as the Microchip KSZ9031RNX) may be connected to either port, but in that case the signal

connection will be RX-to-TX, and TX-to-RX.

The RGMII/MII/RMII interfaces are powered by the VDDIO power supply.

FIGURE 4-17:

IN-BAND MANAGEMENT FRAME FORMAT

LSB

MSB

PREAMBLE

SFD

7 Bytes

1 Byte

DES. ADDRESS

6 Bytes

IBAF TAG TYPE

2 Bytes

SRC. ADDRESS

6 Bytes

IBAF TAG CONTROL INFO.

2 Bytes

46 bit address

i/g

u/l

i/g=0, Individual Address; i/g=1, Group Address

u/l=0, Globally Admin. Addr. u/l=1, Locally Admin. Addr.

2 Bytes

MAC LENGTH/TYPE

2 Bytes

TPID

10011000

00000000

0x9800 for 98xx Family

Reserved

010xxxxx

11111110

Sequence #

cfi

3 bits of Priority, 1 bit of Canonical Format Indicator = 0

4 bits of mode, 8 bits of sequence #

IBAF TAG

2 Bytes

ACCESS COMMAND

4 Bytes

DATA

4 Bytes

ACCESS CODE

4 Bytes

EXTENSION

Variable

FRAME CHECK SEQUENCE

4 Bytes

PAD

Variable

IBAF

Layer 3

Data

38/42/46

– 1500

MAC

DATA

0eeeeAAAAAAAA

OP.

Code

Bits Transmitted from Left to Right

mode

ACCESS FORMAT

Reserved

0x0001 = Rd/Wr,

0x0002 = Burst

ACCESS COMMAND/DATA

DATA

AAAAAAAAAAAAAAAA

COMMAND = 0x0001 (Rd/Wr)

0000000000000

OP.

Code

00000000000aaaaa

COMMAND = 0x0002 (Dump)

0xdddddddd

COMMAND = 0x0001 (Rd/Wr)

3 bits of OP code:

001 = READ, 010 = WRITE,

100 = WAIT on 0, 101 = WAIT on 1,

110 = MODIFY to 0, 111 = MODIFY to 1,

000 = end of command list

eeee = Byte enable

AAAA..AAAA[23:0] = Register Address

000000AAAAAAAA

Dir

AAAAAAAAAAAAAAAA

COMMAND = 0x0002 (Burst)

2 bits of Direction:

01 = READ, 10 = WRITE,

AAAA..AAAA[23:0] = Starting Register Address

0xmaskmask

COMMAND = 0x0001 (WAIT/

MODIFY)

Mask (1) = bit in reg. to be tested for OP code 100/101

set (1) = bit to be set to 0/1 based on OP code 110/111

dddddddd = data written/read

26 0's and 6 bits of burst count

COMMAND = 0x0002 (Burst)
