KSZ9563RNXI-TR datasheet(148/226 Pages) MICROCHIP

148 / 226 page

KSZ9563R

DS00002419D-page 148

 2017-2018 Microchip Technology Inc.

Parallel Detect Fault Interrupt Enable

1 = Enable parallel detect fault interrupt

0 = Disable parallel detect fault interrupt

R/W

Link Partner Acknowledge Interrupt Enable

1 = Enable link partner acknowledge interrupt

0 = Disable link partner acknowledge interrupt

R/W

Link Down Interrupt Enable

1 = Enable link down interrupt

0 = Disable link down interrupt

R/W

Remote Fault Interrupt Enable

1 = Enable remote fault interrupt

0 = Disable remote fault interrupt

R/W

Link Up Interrupt Enable

1 = Enable link up interrupt

0 = Disable link up interrupt

R/W

Jabber Interrupt

1 = Jabber occurred

0 = Jabber did not occur

Receive Error Interrupt

1 = Receive error occurred

0 = Receive error did not occur

Page Received Interrupt

1 = Page receive occurred

0 = Page receive did not occur

Parallel Detect Fault Interrupt

1 = Parallel detect fault occurred

0 = Parallel detect fault did not occur

Link Partner Acknowledge Interrupt

1 = Link partner acknowledge occurred

0 = Link partner acknowledge did not occur

Link Down Interrupt

1 = Link down occurred

0 = Link down did not occur

Remote Fault Interrupt

1 = Remote fault occurred

0 = Remote fault did not occur

Link Up Interrupt

1 = Link up occurred

0 = Link up did not occur

Bits

Description

Type

Default
