PACKAGE DIMENSIONS in millimeters

BULK PACKAGING

Standard shipping for TVCast is in conductive plastic bags. The packing quantity is determined by weight and the number of

components per carton may vary by a maximum of ± 0.3 %.

ORDERING INFORMATION

Note

• d = “digit”, please consult the list of available devices create a valid part number

Example: TSOP59338

PACKAGING QUANTITY

• 400 pieces per bag (each bag is individually boxed)

• 6 bags per carton

T

S

P

d

ddd

d

O = receiver

S = sensor

IC and

package type

AGC

Frequency

Drawing-No.: GO-100220.01-4_Rev03_1

issue H: 18.03.16

Not indicated tolerances ± 0.2

Technical drawings

according to DIN

specification.

(4 x)

(3.05)

Area not plane

6.8

5.9

R1.5

R1.5

0.5

R1.5

(1.6)

2.6

0.9

Marking area

2.6

(1)

(4 x)

(Ø 0.75)

1.15

0.4 ± 0.1

0.6 max.

1.27 nom.

1.27 nom.

GND

GND

Out

V

S

3 x 1.27 = 3.81

Proposed hole layout

from component side

(for reference only)

(1.27)

(1.27)

(1.27)
