3 / 13 page ![]() Rev. 1.1 January 2022 www.aosmd.com Page 3 of 13 AOZ9511QV ALPHA & OMEGA SEMIC ONDUCT OR Electrical Characteristics TA = -40°C to +125°C, unless otherwise specified. Symbol Parameter Conditions Min Typ Max Units General VUVLO_R VCC UVLO Rising VIN=12V, VCC increase, Monitor DVS from low to high 4.3 V VUVLO_F VCC UVLO Falling VIN=12V, VCC decrease, Monitor DVS from high to low 4.2 V VBUVLO_R VB-VOUT UVLO Rising VIN=20V, (VB -VOUT) increase, Monitor VOUT from low to high 4.3 V VBUVLO_F VB-VOUT UVLO Falling VIN=20V, (VB -VOUT) decrease, Monitor VOUT from high to low 4.2 V IVIN_QC IVIN Quiescent Current VIN=12V, VCC=5V, HIN=LIN=0V, DVS=100kΩ 20 μA IVCC_QC IVCC Quiescent Current VIN=12V, VCC=5V, HIN=LIN=0V, DVS=100kΩ 180 μA IVB-VOUT_QC IVB-VOUT Quiescent Current HIN/LIN=0V, VOUT=1V, (VB-VOUT)=5V, 40 mA VHLIN_L HIN/LIN Logic Low Voltage VIN=12V 0.7 0.9 1.1 V VHLIN_H HIN/LIN Logic High Voltage VIN=12V 1.2 1.4 1.6 V RHLIN_IN HIN/LIN Input Pull Low Impedance 280 kΩ tHIN_RP HIN Rising Propagation Delay VIN=10V, VCC=5V, DVS=20kΩ, VOUT to GND=100Ω, HIN=Low to High, Monitor VOUT Low to High 62 87 110 ns tHIN_FP HIN Falling Propagation Delay VIN=10V, VCC=5V, DVS=20kΩ, VOUT to GND=100Ω, HIN=High to Low, Monitor VOUT High to Low 60 86 110 ns tLIN_RP LIN Rising Propagation Delay VIN=10V, VCC=5V, DVS=20kΩ, VOUT to GND=100Ω, LIN=Low to High, Monitor VOUT High to Low 72 91 105 ns tLIN_FP LIN Falling Propagation Delay VIN=10V, VCC=5V, DVS=20kΩ, VOUT to GND=100Ω, LIN=High to Low, Monitor VOUT Low to High 50 75 95 ns Absolute Maximum Ratings Exceeding the Absolute Maximum ratings may damage the device. Parameter Rating VIN to AGND -0.3V to +30V VOUT to GND -0.3V to +30V VB to AGND -0.3V to +40V VB to VOUT -0.3V to +6V DVS, VCC to AGND -0.3V to +6V PGND to AGND -0.3V to +1V Junction Temperature (TJ) +150°C Storage Temperature (TS) -65°C to +150°C ESD Rating ±2kV Recommended Operating Conditions The device is not guaranteed to operate beyond the Maximum Recommended Operating Conditions. Parameter Rating Supply Voltage (VIN) 3.8V to 28V Supply Voltage (VCC) 4.75V to 5.5V Ambient Temperature (TA) -40°C to +125°C Package Thermal Resistance (ΘJC) (ΘJA) 0.6°C/W 40°C/W |
|
|
