This is information on a product in full production.

October 2017

DocID12943 Rev 14

1/47

M24M01-R M24M01-DF

1-Mbit serial I²C bus EEPROM

Datasheet

- production data

Features

• Compatible with all I2C bus modes:

–1 MHz

– 400 kHz

– 100 kHz

• Memory array:

– 1 Mbit (128 Kbyte) of EEPROM

– Page size: 256 byte

– Additional Write lockable page (M24M01-D

order codes)

• Single supply voltage and high speed:

– 1 MHz clock from 1.7 V to 5.5 V

• Write:

– Byte Write within 5 ms

– Page Write within 5 ms

• Operating temperature range:

– from -40 °C up to +85 °C

• Random and sequential Read modes

• Write protect of the whole memory array

• Enhanced ESD/Latch-Up protection

• More than 4 million Write cycles

• More than 200-years data retention

Packages

• SO8 ECOPACK2®

• TSSOP8 ECOPACK2®

• WLCSP ECOPACK2®

• Unsawn wafer (each die is tested)

SO8 (MN)

150 mil width

TSSOP8 (DW)

169 mil width

WLCSP (CS, CX)

Unsawn wafer

www.st.com
