background image
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
1
isc Triacs
ISC3B433W
FEATURES
·
With TO-247 package.
·
triacs provide good commutation capability,
which is suitable for general purpose AC switching
and voltage regulation, and can be used in static relays,
heating regulation, induction motor stating circuits.
·
Minimum Lot-to-Lot variations for robust device performance
and reliable operation
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
MIN
UNIT
VDRM
Repetitive peak off-state voltage
1600
V
VRRM
Repetitive peak off-state voltage
1600
V
IT(RMS)
RMS on-state current (full sine wave)
80
A
ITSM
Non-repetitive peak on-state current
tp=20ms
800
A
I2t
I2t value for fusing (tp=10ms)
3200
A2S
PG(AV)
Average gate power dissipation
2
W
PGM
Peak gate power
10
W
Tj
Operating junction temperature
-40~125
℃
Tstg
Storage temperature
-40~150
℃
Rth(j-c)
Thermal resistance, junction to case
0.35
℃
/W
