Ordering Information

“C” is the device revision designator (will not correlate with the datasheet revision).

“G” denotes Pb-free configuration, RoHS compliant.

Table 37. Ordering Information

Number of

Clock Outputs

Output

Impedance

Orderable Part

Number

Package

Temperature

Range

Part Number Suffix and Shipping Method

285

9SQL4952CNLGI

24-VFQFPN

-40°C to +85°C

None = Trays

“8” = Tape and Reel, Pin 1 Orientation: EIA-481C

(see Table 38 for more details)

9SQL4952CNLGI8

485

9SQL4954CNLGI

32-VFQFPN

9SQL4954CNLGI8

885

9SQL4958CNDGI

48-VFQFPN

9SQL4958CNDGI8

Table 38. Pin 1 Orientation in Tape and Reel Packaging

Part Number Suffix

Pin 1 Orientation

Illustration

8

Quadrant 1 (EIA-481-C)

USER DIRECTION OF FEED

Correct Pin 1 ORIENTATION

CARRIER TAPE TOPSIDE

(Round Sprocket Holes)
