9SQL4952/9SQL4954/9SQL4958 Datasheet

1 This is the current required to have the REF output running in Wake-on-LAN mode (Byte 3, bit 5 = 1).

1 This is the current required to have the REF output running in Wake-on-LAN mode (Byte 3, bit 5 = 1).

1 This is the current required to have the REF output running in Wake-on-LAN mode (Byte 3, bit 5 = 1).

Table 10. Current Consumption – 9SQL4952

Parameter

Symbol

Conditions

Minimum Typical Maximum Units Notes

Operating Supply

Current

IDDAOP VDDA, all outputs active at 100MHz.

13

17

mA

IDDOP

All VDD, except VDDA, all outputs active at100MHz.

18

23

mA

Wake-on-LAN Current

(Power down state and

Byte 3, bit 5 = '1')

IDDAPD VDDA, DIF outputs off, REF output running.

0.9

1.5

mA

1

IDDPD

All VDD, except VDDA, DIF outputs off, REF output

running.

5.7

8

mA

1

Power Down Current

(Power down state and

Byte 3, bit 5 = '0')

IDDAPD

VDDA, all outputs off.

0.9

1.5

mA

IDDPD

All VDD, except VDDA, all outputs off.

1.7

2.5

mA

Table 11. Current Consumption – 9SQL4954

Parameter

Symbol

Conditions

Minimum Typical Maximum Units Notes

Operating Supply

Current

IDDAOP VDDA, all outputs active at 100MHz.

13

17

mA

IDDOP

All other VDD, except VDDA, all outputs active

at100MHz.

30

39

mA

Wake-on-LAN Current

(Power down state and

Byte 3, bit 5 = '1')

IDDAPD

VDDA, DIF outputs off, REF output running.

0.9

1.5

mA

1

IDDPD

All other VDD, except VDDA, DIF outputs off, REF

output running.

5.9

8.0

mA

1

Power Down Current

(Power down state and

Byte 3, bit 5 = '0')

IDDAPD VDDA, all outputs off.

0.9

1.5

mA

IDDPD

All other VDD, except VDDA, all outputs off.

1.5

2.5

mA

Table 12. Current Consumption – 9SQL4958

Parameter

Symbol

Conditions

Minimum Typical Maximum Units Notes

Operating Supply

Current

IDDAOP VDDA, all outputs active at 100MHz.

14

19

mA

IDDOP

All VDD, except VDDA and VDDIO, all outputs active

at100MHz.

18

24

mA

IDDIOOP VDDIO, all outputs active at100MHz.

30

37

mA

Wake-on-LAN Current

(Power down state and

Byte 3, bit 5 = '1')

IDDAPD VDDA, DIF outputs off, REF output running.

0.9

1.5

mA

1

IDDPD

All VDD, except VDDA and VDDIO, DIF outputs off, REF

output running.

5.2

8

mA

1

IDDIOOP VDDIO, DIF outputs off, REF output running.

0.04

0.1

mA

1

Power Down Current

(Power down state and

Byte 3, bit 5 = '0')

IDDAPD VDDA, all outputs off.

0.9

1.5

mA

IDDPD

All VDD, except VDDA and VDDIO, all outputs off.

1.7

2.3

mA

IDDIOOP VDDIO, all outputs off.

0.04

0.1

mA
