Reference
Part number
Description
Value
Manufacturer
R3
0603 SMD resistor
Not mounted (330 Ω)
C1
0603 MLCC
Not mounted (1 µF, 35 V)
Ciso+, Ciso-
0805 MLCC
Not mounted (1 µF, 50 V)
Dz1
Zener diode
Not mounted (Vz1 = 12
V)
Dz2
4.7 V Zener diode
Not mounted (Vz1 = 4.7
V)
Q1
2STR1215
NPN power transistor
Not mounted
ST
Figure 52. STEVAL-L6983IV1 (top layer)
Figure 53. STEVAL-L6983IV1 (bottom layer)
L6983I
Application board
DS14040 - Rev 1
page 46/56
