Technical Data ELX1211

Effective October 2022

Supersedes June 2022

ACE2V3225

Automotive grade common-mode chip inductor

Product features

•

AEC-Q200 qualified

•

Compliant to OPEN Alliance 2.0

•

1210 (3225 metric) package

•

Moisture sensitivity level (MSL): 1

Applications

•

Ethernet architectures

•

Advanced driver assistance systems (ADAS)

•

Infotainment, safety cameras, sensors,

•

Electric vehicle (xEV)

•

Powertrain

Environmental compliance and general

specifications

•

Storage temperature rang (Component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

Pb

HALOGEN

HF

FREE
