3 / 24 page  Preliminary Technical Data ADL5350 PrC | Page 3 of 24 SPECIFICATIONS 820 MHz RECEIVE PERFORMANCE VS = 3 V, TA = 25°C, LO power = 4 dBm, re: 50 Ω, unless otherwise noted. Table 1. Parameter Min Typ Max Unit Conditions RF Frequency Range 750 850 975 MHz LO Frequency Range 500 780 945 MHz Low Side LO IF Frequency Range 30 70 250 MHz Conversion Loss 6.3 dB fRF = 820 MHz, fLO = 750 MHz, fIF = 70 MHz SSB Noise Figure 5.6 dB fRF = 820 MHz, fLO = 750 MHz, fIF = 70 MHz Input Third-Order Intercept 27.6 dBm fRF1 = 819 MHz, fRF2 = 821 MHz, fLO = 750 MHz fIF = 70 MHz, each RF tone 0 dBm Input 1 dB Compression Point 17.8 dBm fRF = 820 MHz, fLO = 750 MHz, fIF = 70 MHz LO to IF Leakage −28 dBc LO Power = 4 dBm, fRF = 820 MHz, fLO = 750 MHz LO to RF Leakage −16 dBc LO Power = 4 dBm, fRF = 820 MHz, fLO = 750 MHz RF to IF Leakage −17 dBc RF Power = 0 dBm, fRF = 820 MHz, fLO = 750 MHz IF/2 Spurious −50 dBc RF Power = 0 dBm, fRF = 820 MHz, fLO = 750 MHz Supply Voltage 2.7 3 5.5 V Supply Current 10 mA LO Power = 4 dBm 1950 MHz RECEIVE PERFORMANCE VS = 3 V, TA = 25°C, LO power = 6 dBm, re: 50 Ω, unless otherwise noted. Table 2. Parameter Min Typ Max Unit Conditions RF Frequency Range 1800 1950 2050 MHz LO Frequency Range 1420 1760 2000 MHz Low Side LO IF Frequency Range 50 190 380 MHz Conversion Loss 7.2 dB fRF = 1950 MHz, fLO = 1760 MHz, fIF =190 MHz SSB Noise Figure 6.8 dB fRF = 1950 MHz, fLO = 1760 MHz, fIF =190 MHz Input Third-Order Intercept 26.6 dBm fRF1 = 1949 MHz, fRF2 = 1951 MHz, fLO = 1760 MHz fIF = 190 MHz, each RF tone 0 dBm Input 1 dB Compression Point 16 dBm fRF = 1950 MHz, fLO = 1760 MHz, fIF =190 MHz LO to IF Leakage −12.5 dBc LO Power = 6 dBm, fRF = 1950 MHz, fLO = 1760 MHz LO to RF Leakage −10.5 dBc LO Power = 6 dBm, fRF = 1950 MHz, fLO = 1760 MHz RF to IF Leakage −10 dBc RF Power = 0 dBm, fRF = 1950 MHz, fLO = 1760 MHz IF/2 Spurious −54 dBc RF Power = 0 dBm, fRF = 1950 MHz, fLO = 1760 MHz Supply Voltage 2.7 3 5.5 V Supply Current 24 mA LO Power = 6 dBm |
|
|
