HPC-ADSC / HPC-RPSC

Unit: mm

Block Diagram

Dimension

Unit: mm

Ordering Information

Part Number

COM Express

Type

CPU

Memory Display

LVDS

Storage

LAN

USB

UART

Expansion

Power Temperature

Other

HPC-RPSC-A10-0001 COM-HPC

12th/13th Gen Intel® Core™ Series DDR5 x 2

DDI x 3

eDP

M.2 2280 M-Key i226-LM x 2

USB 2.0 x 8, USB 3.2 x 5

(Up to Gen 2 support)

4-Wire UART x 2

PEG[x16] x1

PCIe [x4] x3

PCIe [x1] x8

12V

0°C - 60°C

eSPI, SPI, I2C,

SMBus, GPIO

12th/13th Gen

Intel® Core™

Processor SoC

DMI x8 Gen4

COM-

HPC_Row

EF/GH

Embedded

Controller

IT8528

BIOS

Channel B

Intel® GbE

PHY I226-LM

COM-

HPC_Row

AB/CD

USB3.2 20Gpbs x 2

PCIe [x1] (Gen3) *8

SPI

PCIe [x4] (Gen4)

SATA3.0 *2

USB 2.0 *8

PCIe[x1]

2.5GBE

TPM2.0

4-Wire UART *2

I2C/GPIO/SMBus/HWM/ WDT

PCH R680E

BGA1045

eSPI – LPC

Bridge

SPI

DDI *2

DDI * 1

PCIe [x4] (Gen4)*1

PCIe [x16] (Gen5) *1

eSPI

LPC

DDR5 SO-DIMM*1

Channel A

eDP

PCIe [x4] (Gen4) *2

USB3.2 10Gpbs x 4

Intel

GbE PHY

i226LM

PCIe[x1]

2.5GBE

DDR5 SO-DIMM*1

eSPI

M.2_2280 M-Key
