AD8251

Preliminary Technical Data

Rev. PrB | Page 6 of 8

ABSOLUTE MAXIMUM RATINGS

Table 2. AD8251 Absolute Maximum Ratings

Parameter

Rating

Supply Voltage

+/-14V

Power Dissipation

See Figure 2

Output Short Circuit Current

Common-Mode Input Voltage

-Vs – 0.5 V to +Vs + 0.5 V

Differential Input Voltage

V

Storage Temperature

–65°C to +125°C

Operating Temperature Range

–40°C to +85°C

Lead Temperature Range

(Soldering 10 sec)

°C

Junction Temperature

°C

°C/W

Board)

Package Glass Transition

Temperature

°C

ESD (Human Body Model)

kV

ESD (Charge Device Model)

kV

ESD (Machine Model)

kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only and functional operation of the device at these or

any other condition s above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
