Technical Data 10920

Effective June 2019

XVM-259 Supercapacitor

PCBA Module

Description

Eaton supercapacitors are high reliability, high

power, ultra-high capacitance energy storage

devices utilizing electric double layer capacitor

(EDLC) construction combined with proprietary

materials and processes. This combination of

advanced technologies allows Eaton to offer a

wide variety of capacitor solutions tailored to

applications for backup power, pulse power and

hybrid power systems.

They can be applied as the sole energy storage

or in combination with batteries to optimize cost,

life time and run time. System requirements can

range from a few watts to megawatts.

All products feature low ESR for high power

density with environmentally friendly materials

for a green power solution. Eaton supercapacitors

are maintenance-free with design lifetimes up to

20 years* and operating temperatures down to

-40 °C and up to +85 °C.

Features

•

Energy storage module for ride-through power

•

Long life energy storage, up to 20 years*

•

Easy integration into rack based system

•

Wide operating temperature range

•

High voltage for maximum efficiency

•

High efficiency (>98%) under broad operating

conditions

•

High reliability, green solution

•

Low operating costs and maintenance free

Applications

•

UPS Backup power

•

Material handling systems

•

Peak power shaving, pulse power

HALOGEN

HF

FREE

* Supercapacitor lifetimes vary based on charge voltage and

temperature. See Eaton’s application guidelines or contact

your local Eaton sales representative for more information on

lifetime estimates.
