AD6654
Rev. 0 | Page 21 of 88
Table 12. Pin Listing for Power, Ground, and Data Buses
Name
Pin Number
AVDD
A13, A14, B13, B14, C12, C13, C14, D13, D14, E13, E14, F13, F14, G13, G14, H13, H14, J13, J14, K13, K14, L13, L14, M13,
M14, N13, N14, P13, P14
AGND
A15, A16, B15, B16, C15, C16, D15, D16, E15, E16, F15, G15, G16, H15, J15, J16, K15, K16, L15, M15, N15, N16, P15, P16,
R13, R14, R15, T13, T15
DRVDD
D12, E12, F12, G12, H12, J12, K12, L12, M12, N12, P12, R12
VDDIO
E3, E9, E10, E11, F9, F10, F11, L6, L7, L8, M6, M7, M8
VDDCORE
E4, E6, E7, E8, F6, F7, F8, L9, L10, L11, M9, M10, M11
DGND
A1, G1, G6, G7, G8, G9, G10, G11, H6, H7, H8, H9, H10, H11, J1, J6, J7, J8, J9, J10, J11, K6, K7, K8, K9, K10, K11, N9, N10,
N11, T1, T8
PADATA[15:0]
N5, D6, R4, C6,T3, B6, R3, D7, N4, C7, P4, T2, A7, N3, P3, B7
PBDATA[15:0]
D9, N7, B9, C9, B10, T5, A10, P6, P7, C10, P5, R7, T6, R6, R9, D10
PCDATA[15:0]
C5, N1, D5, A5, N2, B5, D4, M4, K5, M3, L5, L3, L2, M2, M1, L4
D[15:0]
J3, F5, G4, H1, H3, G5, J2, B1, G2, G3, H4, H2, A3, F2, A2, F3
A[7:0]
K3, J5, K4, L1, K2, K1, H5, J4
