Position Sensors

EN Series

Environment-Sealed Limit Switches

Honeywell Sensing and Control 1-800-537-6945 USA

1-815-235-6847 International 1-416-293-8111 Canada

25

FEATURES

Environment-proof seal per Symbol 4,

MIL-S-8805

Qualified to MIL-S-8805

Standard temperature range: –65

°Fto

+185°F (–54°Cto +85°C)

High temperature range listings: –65

°F

to

+257°F (–54°Cto +125°C)

Meets or exceeds mechanical and

electrical life as defined in MIL-S-8805

1EN1-6

ELECTRICAL SPECIFICATIONS

The electrical ratings charted below are referenced in the order guides. Refer to appro-

priate MIL specification for ratings applicable to specific switches.

DC RATINGS (Amps)

Sea Level

50,000 Feet

Rating2

Code

Voltage

Inrush Motor

Res.

Ind.

Inrush Motor

Res.

Ind.

A

28 VDC

24

4

4

2

24

43

41

2

B

28 VDC

36610336

63

10

3

C

28 VDC

30

5

15

10

30

53

15

10

D

28 VDC

24

4

5

3

N/A

E

28 VDC

N/A

1

.5

N/A

1

.5

F

28 VDC

24

4

7

4

24

43

7

2.5

Notes:

1

5 amps for rotary switches

2

For other electrical data, contact your nearest MICRO SWITCH Sales Office. MIL-S-8805 ratings apply when

this specification is invoked.

3

Application information only.

AC RATINGS (Amps)

Sea Level

Motor

Rating

Code

Voltage

Make

Break

Res.

Ind.

A&D

125/460 VAC @ 60 Hz

24

4

5

3

125 VAC @ 400 Hz

24

4

5

5

B

125/250 VAC @ 60 Hz

20

3

5

5

460VAC@60Hz

20

3

3

3

125 VAC @ 400 Hz

36

6

10

6

C

125/250 VAC @ 60 Hz

20

3

5

5

460VAC@60Hz

20

3

3

3

125 VAC @ 400 Hz

30

5

10

6

F

125/460 VAC @ 60 Hz

12

2

2

2

125 VAC @ 400 Hz

24

4

5

5

CIRCUITRY

Two Single-Pole

Double-Throw

Circuits

Four Single-Pole

Double-Throw

Circuits

Two Circuit

Double Break

Four Circuit

Double Break
