KHS Series Datasheet

Type

KHS400 KHS500 KHS700 KHS800 KHS10A KHS11A KHS17A

Historical Part Number

KH206-8

KH208-8

KH210-8

KH212-8

KH214-8

KH216-8

KH218-8

Derating Linear

[ºC]

70…350 (0W)

Climatic Category

55/200/21

Failure Rate

(Total

, ϑ

0 ,

max, 60[%] cont. lev.)

[10-9* h-1]

appr. 100 depends on value

Endurance

IEC60115-1 clause 4.25

(P70, @ 70[°C], 1000[h])

±[%]

Short Time Overload

IEC60115-1 clause 4.13

(10 times rated power for 5 seconds)

±[%]

2,0

Damp Heat, Steady State

IEC60115-1 clause 4.24

(40[°C], 93[% r.h.], 56[d])

±[%]

Climatic Sequence

IEC60115-1 clause 4.23

±[%]

Resistance to Soldering Heat

IEC60115-1 clause 4.18

(260±5[°C], 3,5±1[s])

±[%]

0,2

Terminal Strength

±[%]

Terminal Tensile Strength

[N]

Solderability

IEC60068-2-20

(245±5[ºC] 3±0,5[s])

Solder bath method (> 95% coverage)

Marking

IEC60062

Printed in clear

New P/Nr.

Type

Historical

P/N:

± 10

[%]

± 5

[%]

New P/Nr.

Type

Historical

P/N:

400 ± 50 ppm/K

-20 ± 60 ppm/K

0 ± 10 ppm/K

KHS400

KH206 - 8

0R051

0R1

KHS400

KH206 - 8

≥ 0R051

≤ 0R2

≥ 0R22

≤ 300R

≥ 330R

≤ 12K

KHS500

KH208 - 8

0R075

0R15

KHS500

KH208 - 8

≥ 0R075

≤ 0R3

≥ 0R33

≤ 470R

≥ 510R

≤ 15K

KHS700

KH210 - 8

0R11

0R33

KHS700

KH210 - 8

≥ 0R11

≤ 0R68

≥ 0R75

≤ 910R

≥ 1K

≤ 33K

KHS800

KH212 - 8

0R075

0R15

KHS800

KH212 - 8

≥ 0R075

≤ 0R3

≥ 0R33

≤ 470R

≥ 510R

≤ 15K

KHS10A

KH214 - 8

0R11

0R33

KHS10A

KH214 - 8

≥ 0R11

≤ 0R68

≥ 0R75

≤ 910R

≥ 1K

≤ 33K

KHS11A

KH216 - 8

0R15

0R51

KHS11A

KH216 - 8

≥ 0R15

≤ 1R

≥ 1R1

≤ 1K3

≥ 1K5

≤ 47K

KHS17A

KH218 - 8

0R27

0R91

KHS17A

KH218 - 8

≥ 0R27

≤ 1R6

≥ 1R8

≤ 2K4

≥ 2K7

≤ 82K

RESISTANCE RANGE (minimum)

TEMPERATURE COEFFICIENT
