1 / 10 page  May 2006 Rev 1 1/10 STTH2002 Ultrafast recovery diode Main product characteristics Features and benefits ■ Ultrafast switching ■ Low reverse current ■ Low thermal resistance ■ Reduces switching and conduction losses ■ High Tj ■ Insulating voltage: 2500 Vrms ■ Capacitance: 7 pF Description Single rectifier suited for switch mode power supply and high frequency DC to DC converter. Packaged in D²PAK, TO-220AC and insulated TO- 220AC, this device is intended for low voltage, high frequency inverters, free wheeling and polarity protection applications Order codes IF(AV) 20 A VRRM 200 V Tj (max) 175° C VF (typ) 0.86 V trr (typ) 16 ns Part Number Marking STTH2002D STTH2002 STTH2002DI STTH2002 STTH2002G STTH2002 STTH2002G-TR STTH2002 TO-220AC STTH2002D TO-220ACins STTH2002DI DPAK STTH2002G 2 A A A A K K K K K NC www.st.com |
