IP5407

V1.31

http://www.injoinic.com

1 / 13

2A charge 2.1A / 2.4A discharge integrated DCP

function mobile power SOC

1 Features



Charge and discharge of synchronous

switch

 2.1A / 2.4A synchronous boost conversion,

2.0A synchronous switch charging

 Boost efficiency up to 93%

 Charging efficiency up to 91%

 Built-in power supply path management,

supporting charging and discharging at the

same time

 Double click to turn on the Output supports

linear compensation of 60mV



charging

 Automatically adjust the charging current to

match the output capability of the adapter

 Support 4.20V,4.35V batteries



Power display

 Support 4/2/1 LED power display

Supports 4 light models: IP5407

Support 2/1 light models: IP5407_2D1D



Multifunction

 Built-in floodlight driver

 Automatically detect phone insertion and

removal

 Integrated mobile phone charging current

intelligent identification DCP

 Support battery NTC temperature protection.



Low power consumption

 Output fixed normally open 5V

 Standby power consumption is less than

150uA



BOM are simple and few

 Built-in power MOS, single inductor realizes

charging and discharging



Multiple protections and high reliability

 Output over-current, over-voltage,

short-circuit protection

 Input overvoltage, overcharge, overdischarge,

overcurrent discharge protection

 over-temperature protection

 ESD:4KV, instantaneous withstand

voltage :11V

2 application



Power bank



Mobile phones, tablets and other portable

devices

3 Introduction

IP5407 is a multi-function power management

soc with integrated boost converter, lithium battery

charge management, and battery power indication,

providing a complete power solution for mobile

power.

IP5407 has high integration and rich functions,

so it only needs few peripheral devices in

application，effectively reduce the size of the overall

solution and reduce BOM cost.

IP5407's synchronous boost system provides

2.1A / 2.4A output current, and the conversion

efficiency is as high as 93%. At light load, it

automatically turns off the LED power indicator

and maintains the 5V voltage output to sleep, and

the quiescent current drops below 150uA.

IP5407 uses switch charging technology to

provide 2.0a current at the input, with charging

efficiency up to 91%.Built-in IC internal

temperature and input voltage detection and

intelligent adjustment of charging current.

IP5407 supports 4, 2, 1 LED power display and

lighting functions.

IP5407 is available in ESOP8 package.
