IP5322P 데이터시트(PDF) 21 Page - Injoinic Technology Co.,Ltd.

부품명 IP5322P
상세설명  Supports two-way SCP, VOOC, PD3.0 and other fast charging protocols, supports 2~5 cells in series Integrated buck-boost driver, maximum power 100W mobile power supply SOC
PDF  32 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  INJOINIC [Injoinic Technology Co.,Ltd.]
홈페이지  http://www.injoinic.com
Logo INJOINIC - Injoinic Technology Co.,Ltd.

IP5322P 데이터시트(HTML) 21 Page - Injoinic Technology Co.,Ltd.

Back Button IP5322P Datasheet HTML 17Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 18Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 19Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 20Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 21Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 22Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 23Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 24Page - Injoinic Technology Co.,Ltd. IP5322P Datasheet HTML 25Page - Injoinic Technology Co.,Ltd. Next Button
Zoom Inzoom in Zoom Outzoom out
 21 / 32 page
background image
IP5389
V1.2
Email: service@injoinic.com
21 / 32
Copyright © 2021, Injoinic Corp.
充满
亮
亮
亮
亮
75%≤C
亮
亮
亮
1.5Hz 闪烁
50%≤C＜75%
亮
亮
1.5Hz 闪烁
灭
25%≤C＜50%
亮
1.5Hz 闪烁
灭
灭
C＜25%
1.5Hz 闪
烁
灭
灭
灭
放电时
电量
C（%）
D1
D2
D3
D4
C≥75%
亮
亮
亮
亮
50%≤C＜75%
亮
亮
亮
灭
25%≤C＜50%
亮
亮
灭
灭
3%≤C＜25%
亮
灭
灭
灭
0%＜C＜3%
1.0Hz 闪
烁
灭
灭
灭
C=0%
灭
灭
灭
灭
数码管电量显示模式
IP5389 默认支持的数码管如下所示。
数码管
充电
放电
未充满状态
充满状态
电量小于 5%
电量大于 5%
188 型
0-99% 个位
0.5HZ 闪烁
常亮 100%
0-5%个位 1HZ 闪
烁
5%-100% 常亮
5pin 188 型数码管原理图如下：
