UM603S

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 5

www.unisonic.com.tw

QW-R105-033,A

ABSOLUTE MAXIMUM RATINGS (Ta = 25 )

℃

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-0.3 ~ +20

Recommended Operating Voltage

VOPR

+4 ~ +20

Allowable loss

250

Operating Temperature

TOPR

-25 ~ +85

℃

Storage Temperature

TSTG

-40 ~ +125

℃

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS (VCC=5V, Ta=25℃, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Current Consumption

ICC

INA=0V, INB=0V, RL=∞

1.2

1.7

A Amplifier

Output Inverting Voltage

INA =0V, RL=4.3k

2.45

2.50

2.55

Output Sink Current

IO(SINK A) INB =2.7V, INA =0V, VOUT=1.5V

Input Bias Current

II(BIAS A) INA =0V, RL=4.3k

140

PSRR

PSRR(A) INA =0V, RL=4.3k

B Amplifier

Output Inverting Voltage

INB =0V, RL=4.3k

152

160

Output Sink Current

IO(SINK B) INB =0V, INA=0.17V, VOUT=1.5V

Input Bias Current

II(BIAS B) INB =0V, RL=4.3k

140

PSRR

PSRR(B) INB =0V, RL=4.3k
