CD4069
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 7
www.unisonic.com.tw
QW-R502-020,B
AC ELECTRICAL CHARACTERISTICS(Note 1)
(Ta=25℃, CL=50pF, RL=200kΩ, tr and tf ≤ 20 ns, unless otherwise specified)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNIT
Propagation Delay Time from
Input to Output
tPHL or tPLH
VDD=5V
VDD=10V
VDD=15V
50
30
25
90
60
50
ns
Transition Time
tTHL or tTLH
VDD=5V
VDD=10V
VDD=15V
80
50
40
150
100
80
ns
Average Input Capacitance
CIN
Any Gate
6
15
pF
Power Dissipation Capacitance
CPD
Any Gate (Note 3)
12
pF
Note: 1.AC Parameters are guaranteed by DC correlated testing.
2: IOH and IOL are tested one output at a time.
3: CPD determines the no load AC power consumption of any CMOS device.
