AD8571/AD8572/AD8574

Rev. B | Page 5 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

GND to VS + 0.3 V

Differential Input Voltage1

±5.0 V

ESD (Human Body Model)

2000 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

RM, RU, and R Packages

−65°C to +150°C

Operating Temperature Range

AD8571A/AD8572A/AD8574A

−40°C to +125°C

Junction Temperature Range

RM, RU, and R Packages

−65°C to +150°C

Lead Temperature Range (Soldering, 60 sec)

300°C

1 Differential input voltage is limited to ±5.0 V or the supply voltage,

whichever is less.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL CHARACTERISTICS

θJA is specified for the worst-case conditions, that is, θJA is

specified for a device soldered in a circuit board for SOIC and

TSSOP packages.

Table 4. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead MSOP (RM)

190

°C/W

8-Lead TSSOP (RU)

240

°C/W

8-Lead SOIC (R)

158

°C/W

14-Lead TSSOP (RU)

180

°C/W

14-Lead SOIC (R)

120

°C/W
