AD629

Rev. B | Page 5 of 16

TYPICAL PERFORMANCE CHARACTERISTICS

TA = 25°C, VS = ±15 V, unless otherwise noted.

FREQUENCY (Hz)

100

10k

100k

10M

Figure 5. Common-Mode Rejection Ratio vs. Frequency

VOUT (V)

–20

–16

–8

–4

–12

RL = 10kΩ

VS = ±18V

VS = ±15V

VS = ±12V

VS = ±10V

2mV/DIV

4V/DIV

Figure 6. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage

Operating Range vs. Supply Voltage, RL = 10 kΩ (Curves Offset for Clarity)

VOUT (V)

–20

–16

–8

–4

–12

RL = 1kΩ

VS = ±18V

VS = ±15V

VS = ±12V

VS = ±10V

4V/DIV

Figure 7. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage

Operating Range vs. Supply Voltage, RL = 1 kΩ (Curves Offset for Clarity)

POWER SUPPLY VOLTAGE (±V)

400

360

320

280

240

200

160

120

TA = +25°C

TA = +85°C

TA = –40°C

Figure 8. Common-Mode Operating Range vs. Power Supply Voltage

VOUT (V)

–20

–16

–8

–4

–12

RL = 2kΩ

VS = ±18V

VS = ±15V

VS = ±12V

VS = ±10V

4V/DIV

Figure 9. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage

Operating Range vs. Supply Voltage, RL = 2 kΩ (Curves Offset for Clarity)

VOUT (V)

–20

–16

–8

–4

–12

VS = ±5V, RL = 2kΩ

VS = ±5V, RL = 1kΩ

VS = ±2.5V, RL = 1kΩ

1V/DIV

VS = ±5V, RL = 10kΩ

Figure 10. Typical Gain Error Normalized @ VOUT = 0 V and Output Voltage

Operating Range vs. Supply Voltage (Curves Offset for Clarity)
