AD8202

Rev. D | Page 10 of 20

VOS (μV)

TEMPERATURE = –40

°C

Figure 30. VOS Distribution, SOIC, Temperature = −40°C

VOS DRIFT (μV/°C)

VSUPPLY = 5V

TEMPERATURE RANGE =

–40

°C TO +25°C

Figure 31. Offset Drift Distribution, SOIC,

Temperature Range = −40°C to +25°C

VOS DRIFT (μV/°C)

VSUPPLY = 5V

TEMPERATURE RANGE =

°C TO 85°C

Figure 32. Offset Drift Distribution, SOIC,

Temperature Range = 25°C to 85°C

VOS DRIFT (μV/°C)

VSUPPLY = 5V

TEMPERATURE RANGE =

°C TO 125°C

Figure 33. Offset Drift Distribution, SOIC,

Temperature Range = 25°C to 125°C

ERROR (%)

TEMPERATURE = 25

°C

Figure 34. Gain Accuracy, SOIC, Temperature = 25°C

ERROR (%)

TEMPERATURE = 125

°C

Figure 35. Gain Accuracy, SOIC, Temperature = 125°C
