42
AT89C5115
4128F–8051–05/06
Operation Cross Memory Access
Space addressable in read and write are:
•RAM
•
ERAM (Expanded RAM access by movx)
•
EEPROM DATA
•
FM0 ( user flash )
•
Hardware byte
•XROW
•Boot Flash
•
Flash Column latch
The table below provides the different kind of memory which can be accessed from dif-
ferent code location.
Note:
1. RWW: Read While Write
Table 25. Cross Memory Access
Action
RAM
ERAM
Boot FLASH
FM0
E² Data
Hardware
Byte
XROW
boot FLASH
Read
OK
OK
OK
OK
-
Write
-
OK
(1)
OK
(1)
OK
(1)
OK
(1)
FM0
Read
OK)
OK
OK
OK
-
Write
-
OK (idle)
OK
(1)
-OK
