URCZ1284-XX

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 6

www.unisonic.com.tw

QW-R127-001.E



ABSOLUTE MAXIMUM RATING (TA=25°C, unless otherwise specified.)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

5.5

V

Power Rating Per Resistor

PR

100

mW

Package POWER Rating

PP

1

W

Maximum Operating Junction Temperature

TJ

125

°C

ESD Discharge IEC61000-4-2, Contact Discharge

VPP

±8

KV

Operating Temperature Range

TOPR

0 ~ +70

°C

Storage Temperature Range

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Leakage Current

IR

VCC=5.0V

10

μA

Breakdown Voltage

VBR

IR=1mA

6

V

Forward Voltage Drop

VF

IF=50mA

0.9

V
