General Features PCE- RVI 2

Measuring range

1 ... 100,000 cP

Accuracy

<±2 % of measuring range

Resolution

0.01 cP

Repeatability

±0.5 %

Temperature sensor

resistance temperature sensor

Temperature measurement measu-

ring range

0 ... 100 °C / 32 ... 212 °F

Temperature measurement accuracy

0.1 °C

Adjustable measuring time

30 seconds ... 1 hour or endless

Resolution of the measurement time

30 seconds

Adjustable speed

6, 12, 30, 60 RPM

Sample volume

250 ... 400 ml / 8.4 ... 13.5 fl oz (de-

pending on the spindle)

Spindle

L1 ... L4

Interface

RS232 (SUB D9)

Height adjustability

25 cm / 9.8"

Power supply

primary: 100 ... 240 V AC , 50 / 60 Hz

secondary 12 V DC, 2 A

Ambient conditions

5 ... 35 °C / 41 ... 95 °F, <80 RH, non-

condensing

Dimensions

400 x 200 x 430 mm / 15.7 x 7.8 x

16.9"
