NEMA Motor Starter, Type S,

nonreversing, Size 6, 540A, 400

HP at 460 VAC, up to 100 kA

SCCR, 3 phase, 3 pole, Motor

Logic, 380 VAC coil, open

8536SHO2V05H30

Product availability: Non-Stock - Not normally stocked in

distribution facility

Main

Product Type

Motor starter

Product Range

S

Starter Type

Non reversing

Complementary

Nema Size

6

Rated Current

540 A

Number Of Poles

3P

Maximum Voltage Rating

600 V AC

Phase

3 phase

Type Of Overload

Solid state Motor Logic class 10/20

Horsepower Rating

150 HP 200 V AC

200 HP 230 V AC

400 HP 460 V AC

400 HP 575 V AC

Sccr

Circuit-breaker 800 A maximum: 65 kA at 480 V AC

Fuse J 600 A maximum: 100 kA at 600 V AC

Fuse T 600 A maximum: 100 kA at 600 V AC

Fuse RK1 600 A maximum: 100 kA at 600 V AC

Fuse RK5 600 A maximum: 100 kA at 600 V AC

Coil Voltage

380 V AC 50 Hz

Control Circuit Type

Control circuit transformer

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Other Equipment

2 fuses (primary), 2 fuses (secondary)

Terminal Type

Screw clamp terminals

Height

28.06 in (712.72 mm)

Width

12.34 in (313.44 mm)

Depth

9.00 in (228.60 mm)

Environment

Enclosure Type

Not rated (open device)
