Series

DR

Operating Voltage

06: 1-60 VDC

10: 1-100 VDC

Control Voltage

D: 4-32 VDC

Rated Load Current

03: 3 Amps

06: 6 Amps

10: 10 Amps (100 VDC only)

12: 12 Amps

24: 24 Amps (100 VDC only)

ATEX Approvals

Blank: Not ATEX approved

X: ATEX II 3G Ex nA IIC T4 Gc approved (3, 6 and 12 Amps only)

ORDERING OPTIONS

Example : DR06D12

Required for valid part number

For options only and not required for valid part number

(1)

All parameters at 25°C unless otherwise specified.

(2)

See Derating curves

(3)

DC control includes reverse polarity protection.

(4)

Input circuitry incorporates active current limiter.

(5)

Turn-on/off time for 10A is 0.5/0.3 msec & for 24A is 1/0.5 msec.

GENERAL NOTES

AGENCY APPROVALS & CERTIFICATIONS

(3, 6 and 12 Amps only)

DR

06

D

12

SSR Relay, DIN Rail Mount 18mm, 60VDC/12A,4-32VDC In, FET Output
