Input (1)

Description

Parameters

Control Voltage Range (3)

4-32 VDC

Minimum Turn-On Voltage

4.0 VDC

Must Turn-Off Voltage

1.0 VDC

Minimum Input Current for [mA] (4)

9

Maximum Input Current for [mA] (4)

11

Maximum Turn-on Time [msec] (5)

0.6

Maximum Turn-off Time [msec]

0.3

Min/Max stranded/solid wire

22/16 AWG

SPECIFICATIONS

Output (1)

Description

DR06D03 DR10D03 DR06D06 DR10D06 DR10D10

DR06D12 DR10D12 DR10D24

Operating Voltage [VDC]

1-60

1-100

1-60

1-60

1-100

1-60

1-60

1-100

Maximum Load Current [Adc] (2)

3

3

6

6

10

12

12

24

Minimum Load Current [mAdc]

2.5

2.5

2.5

2.5

2.5

2.5

2.5

2.5

Maximum Off-State Leakage Current

@ Rated Voltage [mA]

0.1

0.1

0.1

0.1

0.1

0.1

0.1

0.1

Maximum On-State Voltage Drop @

Rated Current [Vpk]

0.6

0.6

0.6

0.6

0.2

0.6

0.6

0.2

Maximum Surge Current (10ms) [Apk]

60

60

60

60

80

100

100

160

On-State resistance at rated current

[Ohms]

0.6

0.6

0.1

0.1

0.013

0.45

0.45

0.026

Min/Max stranded wire

22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG

Min/Max solid wire

22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG 22/14 AWG

Weight (Typical)

1.76 oz

(50 g)

1.76 oz

(50 g)

1.94 oz

(55 g)

1.76 oz

(50 g)

1.76 oz

(50 g)

3.17 oz

(90 g)

3.17 oz

(90 g)

3.17 oz

(90 g)

General (2)

Description

Parameters

Dielectric Strength, Input/Output/Base

(50/60Hz)

2500 Vrms

Minimum Insulation Resistance (@ 500 V

DC)

109 Ohms

Maximum Capacitance, Input/Output

10 pF

Ambient Operating Temperature Range

-30 to 80 °C

Ambient Storage Temperature Range

-30 to 100 °C

Recommended Terminal Screw Torque

Range

4.4-7.0 lb-in (0.5-0.8 Nm)
