background image
2018 APEX Electronics Ltd. All rights reserved.
www.apex-electronics.com
Materials
Gold plated twin contactor for reliability
Top tape seal for washing process
2, 4, 6, 8, 10, 12 positions
Low-profile, half-pitch, SMD process
Product Features
01
DPICH Series
DIP Switch, top actuated, SMD, compact half-pitch
Specification
Part Number
DPICH
Series
Actuator
F Flush
Positions
02, 04, 06,
08, 10, 12
RoHS compliant
Operating Temperature
-20°C to +85°C
Storage Temperature
-40°C to +85°C
Actuation Life
1,000 cycles
Contact Resistance
100m max.
Position
2, 4, 6, 8, 10, 12
Travel
0.8mm
Insulation Resistance
100M min. at 500VDC
Dielectric Strength
300VAC for 1 min.
Cover
Housing
Actuator
Contactor
Terminal
Tape
PPS
PPS
LCP
Gold plated
alloy copper
Gold plated
brass
Kapton
Terminal
G Gull-wing
Top Tape
N No top tape
T With top tape
Packaging
T Tube
R Reel
