Mounting assembly
I For chassis mounting1) or printed circuit boards
I The set comprises a yoke and a base plate
I Fixing nuts M3 and washers are supplied
Yoke
I Material: Brass clamping yoke (
∅ 2,6 mm) with thread
Base plate
I Material: Aluminum (0,6 mm)
Ordering code
Complete mounting assembly including nuts and washers
B65685-A2000
FPM0009-T
59,8+0,3
64,8+1
M3
69 0,2
_
60,96±0,1
ø3,5+0,15
1) On a chassis the coil former must be mounted with its solder pins upward.
B65685
